| FG-3980E/-DC | FG-3960E/-DC | |
|---|---|---|
| Interfaces and Modules | ||
| Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots |
10 | 6 |
| Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots |
16 | |
| GE RJ45 Management Ports | 2 | |
| USB Ports | 1 | |
| Console Port | 1 | |
| Onboard Storage | – | |
| Included Transceivers | 2x SFP+ (SR 10 GE) | |
| System Performance — Enterprise Traffic Mix | ||
| IPS Throughput | 32 Gbps | 30 Gbps |
| NGFW Throughput | 28 Gbps | 22 Gbps |
| Threat Protection Throughput | 20 Gbps | 13.5 Gbps |
| System Performance and Capacity | ||
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
1.05 Tbps / 1.05 Tbps / 680 Gbps |
620 Gbps/ 610 Gbps/ 370 Gbps |
| Firewall Latency (64 byte, UDP) | 4 μs | |
| Firewall Throughput (Packet per Second) | 1,020 Mpps | 555 Mpps |
| Concurrent Sessions (TCP) | 160 Million | |
| New Sessions/Second (TCP) | 800,000 | 720,000 |
| Firewall Policies | 200,000 | |
| IPsec VPN Throughput (512 byte) | 400 Gbps | 280 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 40,000 | |
| Client-to-Gateway IPsec VPN Tunnels | 200,000 | |
| SSL-VPN Throughput | 9.5 Gbps | 9 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
30,000 | |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 26 Gbps | 23 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 17,000 | 14,000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
12 Million | |
| Application Control Throughput (HTTP 64K) | 55 Gbps | 40 Gbps |
| CAPWAP Throughput (HTTP 64K) | 14 Gbps | 13.5 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 500 | |
| Maximum Number of FortiSwitches Supported | 300 | |
| Maximum Number of FortiAPs (Total / Tunnel) | 8,192 / 4,096 | |
| Maximum Number of FortiTokens | 20,000 | |
| High Availability Configurations | Active / Active, Active / Passive, Clustering | |
| Dimensions and Power | ||
| Height x Width x Length (inches) | 8.8 x 17.2 x 27.3 | |
| Height x Width x Length (mm) | 222 x 437 x 695 | |
| Weight | 106.3 lbs (48.2 kg) | 100.8 lbs (45.8 kg) |
| Form Factor | Rack Mount, 5 RU | |
| AC Power Supply | 100–240V AC, 50–60 Hz | |
| Power Consumption (Average / Maximum) | 1172 / 2350 W | 960 / 2110 W |
| AC Current (Maximum) | 12A@100V, 10A@240V | |
| Heat Dissipation | 8,019 BTU/h | 7,200 BTU/h |
| Redundant Power Supplies (Hot Swappable) | Yes, Hot Swappable | |
| Operating Environment and Certifications | ||
| Operating Temperature | 32–104°F (0–40°C) | |
| Storage Temperature | -31–158°F (-35–70°C) | |
| Humidity | 10–90% non-condensing | |
| Noise Level | 63 dBA | |
| Forced Airflow | Front to Back | |
| Operating Altitude | Up to 7,400 ft (2,250 m) | |
| Compliance | FCC Part 15 Class A, RCM, VCCI, CE, UL/ cUL, CB |
|
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN, USGv6/IPv6 |
|
