| FortiGate 90E | FortiGate 91E | |
|---|---|---|
| Hardware Specifications | ||
| GE RJ45 Ports | 16 | 16 |
| USB Ports | 1 | 1 |
| Console (RJ45) | 1 | 1 |
| Internal Storage | – | 128 GB |
| System Performance | ||
| Firewall Throughput | 4.0 Gbps | |
| Firewall Latency (64 byte UDP packets) | 182 μs | |
| Firewall Throughput (Packets Per Second) | 375 Kpps | |
| Concurrent Sessions (TCP) | 1.2 Million | |
| New Sessions/Second (TCP) | 27,500 | |
| Firewall Policies | 5,000 | |
| IPsec VPN Throughput (512 byte packets) | 160 Mbps | |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 | |
| Client-to-Gateway IPsec VPN Tunnels | 1,000 | |
| SSL-VPN Throughput | 95 Mbps | |
| Concurrent SSL-VPN Users (Recommended Maximum) | 200 | |
| IPS Throughput (HTTP / Enterprise Mix) 1 | 950 / 440 Mbps | |
| SSL Inspection Throughput 2 | 300 Mbps | |
| Application Control Throughput 3 | 450 Mbps | |
| NGFW Throughput 4 | 350 Mbps | |
| Threat Protection Throughput 5 | 210 Mbps | |
| CAPWAP Throughput 6 | 2.2 Gbps | |
| Virtual Domains (Default / Maximum) | 10 / 10 | |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 32 / 16 | |
| Maximum Number of FortiTokens | 100 | |
| Maximum Number of Registered FortiClients | 200 | |
| High Availability Configurations | Active / Active, Active / Passive, Clustering | |
| Dimensions | ||
| Height x Width x Length (inches) | 1.7 x 8.5 x 7.0 | |
| Height x Width x Length (mm) | 43.9 x 216 x 178.5 | |
| Weight | 2.884 lbs (1.308 kg) | 2.917 lbs (1.323 kg) |
| Form Factor | Desktop | |
| Environment | ||
| Power Required | 100–240V AC, 60–50 Hz (External DC Power Adapter) | |
| Maximum Current | 100V AC / 1.5A | 240V AC / 0.75A |
| Power Consumption (Average / Maximum) | 22.8 W / 27.36 W | 23.7 W / 28.44 W |
| Heat Dissipation | 77.7936 BTU/h | 80.8644 BTU/h |
| Operating Temperature | 32–104°F (0–40°C) | |
| Storage Temperature | -31–158°F (-35–70°C) | |
| Humidity | 20–90% non-condensing | |
| Noise Level | 38.8 at 25°C @ 1m (Maximum: 40 dB at 25°C) | |
| Operating Altitude | Up to 7,400 ft (2,250 m) | |
| Compliance | ||
| Safety | FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB | |
| Certifications | ||
| ICSA Labs: Firewall, IPSec, IPS, Antivirus, SSL VPN; USGv6/IPv6 | ||
