| FortiGate 80E | FortiGate 81E | |
|---|---|---|
| Hardware Specifications | ||
| GE RJ45/SFP Shared Media Pairs | 2 | 2 |
| GE RJ45 PoE/+ Ports | 12 | 12 |
| GE RJ45 DMZ/HA Ports | 2 | 2 |
| USB Ports | 1 | 1 |
| Console (RJ45) | 1 | 1 |
| Internal Storage | – | 128 GB |
| System Performance | ||
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 4 / 4 / 4 Gbps | |
| Firewall Latency (64 byte UDP packets) | 3 μs | |
| Firewall Throughput (Packets Per Second) | 6 Mpps | |
| Concurrent Sessions (TCP) | 1.3 Million | |
| New Sessions/Second (TCP) | 30,000 | |
| Firewall Policies | 5,000 | |
| IPsec VPN Throughput (512 byte packets) | 2.5 Gbps | |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 | |
| Client-to-Gateway IPsec VPN Tunnels | 1,000 | |
| SSL-VPN Throughput | 200 Mbps | |
| Concurrent SSL-VPN Users (Recommended Maximum) | 200 | |
| IPS Throughput (HTTP / Enterprise Mix) 1 | 1.5 Gbps / 450 Mbps | |
| SSL Inspection Throughput 2 | 350 Mbps | |
| Application Control Throughput 3 | 800 Mbps | |
| NGFW Throughput 4 | 360 Mbps | |
| Threat Protection Throughput 5 | 250 Mbps | |
| CAPWAP Throughput 6 | 2.2 Gbps | |
| Virtual Domains (Default / Maximum) | 10 / 10 | |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 32 / 16 | |
| Maximum Number of FortiTokens | 100 | |
| Maximum Number of Registered FortiClients | 200 | |
| High Availability Configurations | Active / Active, Active / Passive, Clustering | |
| Dimensions | ||
| Height x Width x Length (inches) | 1.65 x 8.5 x 7 | |
| Height x Width x Length (mm) | 42 x 216 x 178 | |
| Weight | 2.65 lbs (1.2 kg) | |
| Form Factor | Desktop | |
| Environment | ||
| Power Required | 100–240V AC, 50–60 Hz | |
| Maximum Current | 115V AC / 1.2A, 230V AC / 0.6A | |
| Power Consumption (Average / Maximum) | 20 / 137 W | |
| Heat Dissipation | 467.5 BTU/h | |
| Operating Temperature | 32–104°F (0–40°C) | |
| Storage Temperature | -31–158°F (-35–70°C) | |
| Humidity | 20–90% non-condensing | |
| Operating Altitude | Up to 16,404 ft (5,000 m) | |
| Compliance | ||
| Safety | FCC Part 15B, Class B, CE, RCM, VCCI, UL/cUL, CB, BSMI | |
| Certifications | ||
| ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN | ||
