| FORTIGATE 400E | FORTIGATE 401E | |
|---|---|---|
| Interfaces and Modules | ||
| GE RJ45 Interfaces | 16 | |
| GE SFP Slots | 16 | |
| GE RJ45 Management Ports | 2 | |
| USB Ports | 2 | |
| RJ45 Console Port | 1 | |
| Local Storage | NIL | 2x 240 GB SSD |
| Included Transceivers | 2x SFP (SX 1 GE) | |
| System Performance — Enterprise Traffic Mix | ||
| IPS Throughput | 7.8 Gbps | |
| NGFW Throughput | 6 Gbps | |
| Threat Protection Throughput | 5 Gbps | |
| System Performance and Capacity | ||
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
32 / 32 / 24 Gbps | |
| IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
32 / 32 / 24 Gbps | |
| Firewall Latency (64 byte, UDP) | 3 μs | |
| Firewall Throughput (Packet per Second) | 36 Mpps | |
| Concurrent Sessions (TCP) | 4 Million | |
| New Sessions/Second (TCP) | 450,000 | |
| Firewall Policies | 10,000 | |
| IPsec VPN Throughput (512 byte) | 20 Gbps | |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 | |
| Client-to-Gateway IPsec VPN Tunnels | 50,000 | |
| SSL-VPN Throughput | 4.5 Gbps | |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
5,000 | |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 4.8 Gbps | |
| SSL Inspection CPS (IPS, avg. HTTPS) | 4,000 | |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 300,000 | |
| Application Control Throughput (HTTP 64K) | 12 Gbps | |
| CAPWAP Throughput (1444 byte, UDP) | 14.8 Gbps | |
| Virtual Domains (Default / Maximum) | 10 / 10 | |
| Maximum Number of FortiSwitches Supported | 48 | |
| Maximum Number of FortiAPs (Total / Tunnel) | 512 / 256 | |
| Maximum Number of FortiTokens | 5,000 | |
| Maximum Number of Registered FortiClients | 600 | |
| High Availability Configurations | Active-Active, Active-Passive, Clustering | |
| Dimensions and Power | ||
| Height x Width x Length (inches) | 1.75 x 17.0 x 15.0 | |
| Height x Width x Length (mm) | 44.45 x 432 x 380 | |
| Weight | 16.4 lbs (7.4 kg) | 16.9 lbs (7.9 kg) |
| Form Factor | 1 RU | |
| 109 W / 214 W | 115 W / 221 W | |
| Power Source | 100–240V 60–50Hz | |
| Current (Maximum) | 6A | |
| Heat Dissipation | 730 BTU/h | 754 BTU/h |
| Redundant Power Supplies (Hot Swappable) | optional | |
| Operating Environment and Certifications | ||
| Operating Temperature | 32–104°F (0–40°C) | |
| Storage Temperature | -31–158°F (-35–70°C) | |
| Humidity | 10–90% non-condensing | |
| Noise Level | 48 dBA | |
| Operating Altitude | Up to 7,400 ft (2,250 m) | |
| Compliance | FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB | |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 | |
