| FortiGate 200E | FortiGate 201E | |
|---|---|---|
| Hardware Specifications | ||
| GE RJ45 WAN Interfaces | 2 | 2 |
| GE RJ45 Management/HA Ports | 2 | 2 |
| GE RJ45 Ports | 14 | 14 |
| GE SFP Slots | 4 | 4 |
| USB (Client / Server) | 1 / 1 | 1 / 1 |
| Console (RJ45) | 1 | 1 |
| Local Storage | – | 480 GB |
| Included Transceivers | 0 | 0 |
| System Performance | ||
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 20 / 20 / 9 Gbps | |
| Firewall Latency (64 byte UDP packets) | 3 μs | |
| Firewall Throughput (Packets Per Second) | 13.5 Mpps | |
| Concurrent Sessions (TCP) | 2 Million | |
| New Sessions/Second (TCP) | 135,000 | |
| Firewall Policies | 10,000 | |
| IPsec VPN Throughput (512 byte packets) | 9 Gbps | |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 | |
| Client-to-Gateway IPsec VPN Tunnels | 5,000 | |
| SSL-VPN Throughput | 900 Mbps | |
| Concurrent SSL-VPN Users (Recommended Maximum) | 300 | |
| IPS Throughput (HTTP / Enterprise Mix) 1 | 6 Gbps / 2.2 Gbps | |
| SSL Inspection Throughput 2 | 1 Gbps | |
| Application Control Throughput 3 | 3.5 Gbps | |
| NGFW Throughput 4 | 1.8 Gbps | |
| Threat Protection Throughput 5 | 1.2 Gbps | |
| CAPWAP Throughput 6 | 1.5 Gbps | |
| Virtual Domains (Default / Maximum) | 10 / 10 | |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 128 / 64 | |
| Maximum Number of FortiTokens | 1,000 | |
| Maximum Number of Registered FortiClients | 600 | |
| High Availability Configurations | Active / Active, Active / Passive, Clustering | |
| Dimensions | ||
| Height x Width x Length (inches) | 1.7 x 17.0 x 11.9 | |
| Height x Width x Length (mm) | 44 x 432 x 301 | |
| Weight | 11.9 lbs (5.4 kg) | 12.12 lbs (5.5 kg) |
| Form Factor | Rack Mount, 1 RU | |
| Environment | ||
| Power Required | 100–240V AC, 60–50 Hz | |
| Maximum Current | 110 V / 3 A, 220 V / 1.5 A | 110 V / 7 A, 220 V / 3.5 A |
| Power Consumption (Average / Maximum) | 70.98 / 109.9 W | |
| Heat Dissipation | 374.9 BTU/h | |
| Operating Temperature | 32–104°F (0–40°C) | |
| Storage Temperature | -31–158°F (-35–70°C) | |
| Humidity | 10–90% non-condensing | |
| Operating Altitude | Up to 7,400 ft (2,250 m) | |
| Compliance | ||
| Safety | FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI | |
| Certifications | ||
| ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6 | ||
