| FortiGate 600E | FortiGate 601E | |
|---|---|---|
| Interfaces and Modules | ||
| 10 GE SFP+ Slots | 2 | |
| GE RJ45 Interfaces | 8 | |
| GE SFP Slots | 8 | |
| GE RJ45 Management Ports | 2 | |
| USB Ports | 2 | |
| RJ45 Console Port | 1 | |
| Local Storage | NIL | 2x 240 GB SSD |
| Included Transceivers | 2x SFP (SX 1 GE) | |
| System Performance — Enterprise Traffic Mix | ||
| IPS Throughput | 10 Gbps | |
| NGFW Throughput | 9.5 Gbps | |
| Threat Protection Throughput | 7 Gbps | |
| System Performance and Capacity | ||
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
36 / 36 / 27 Gbps | |
| IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
36 / 36 / 27 Gbps | |
| Firewall Latency (64 byte, UDP) | 2 μs | |
| Firewall Throughput (Packet per Second) | 40.5 Mpps | |
| Concurrent Sessions (TCP) | 8 Million | |
| New Sessions/Second (TCP) | 450,000 | |
| Firewall Policies | 10,000 | |
| IPsec VPN Throughput (512 byte) | 20 Gbps | |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 | |
| Client-to-Gateway IPsec VPN Tunnels | 50,000 | |
| SSL-VPN Throughput | 7 Gbps | |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
5,000 | |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 8 Gbps | |
| SSL Inspection CPS (IPS, avg. HTTPS) | 5,500 | |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
800,000 | |
| Application Control Throughput (HTTP 64K) | 15 Gbps | |
| CAPWAP Throughput (HTTP 64K) | 18 Gbps | |
| Virtual Domains (Default / Maximum) | 10 / 10 | |
| Maximum Number of FortiSwitches Supported | 64 | |
| Maximum Number of FortiAPs (Total / Tunnel) | 1,024 / 512 | |
| Maximum Number of FortiTokens | 1,000 | |
| Maximum Number of Registered Endpoints | 2,000 | |
| High Availability Configurations | Active-Active, Active-Passive, Clustering | |
| Dimensions and Power | ||
| Height x Width x Length (inches) | 1.75 x 17.0 x 15.0 | |
| Height x Width x Length (mm) | 44.45 x 432 x 380 | |
| Weight | 16.1 lbs (7.3 kg) | 16.6 lbs (7.5 kg) |
| Form Factor | 1 RU | |
| Power Consumption (Average / Maximum) | 129 W / 244 W | |
| Power Source | 100–240V 60–50Hz | |
| Current (Maximum) | 6A @ 100V | |
| Heat Dissipation | 832 BTU/h | |
| Redundant Power Supplies (Hot Swappable) | optional | |
| Operating Environment and Certifications | ||
| Operating Temperature | 32–104°F (0–40°C) | |
| Storage Temperature | -31–158°F (-35–70°C) | |
| Humidity | 10–90% non-condensing | |
| Noise Level | 59 dBA | |
| Operating Altitude | Up to 7,400 ft (2,250 m) | |
| Compliance | FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB | |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 | |
