FortiGate 5001E/5001E1 |
| 40 GE QSFP+ Ports |
2 |
| 10 GE SFP+ Ports |
2 |
| GE RJ45 Ports |
2 |
| RJ45 Console Port |
1 |
| Included Transceivers |
2x 10 GE SFP+ SR |
| Local Storage |
1x 480 GB SSD (5001E1) |
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) |
80 / 80 / 50 Gbps |
| Firewall Latency (64 byte UDP packets) |
3 μs |
| Firewall Throughput (Packets Per Second) |
75 Mpps |
| Concurrent Sessions (TCP) |
40 Million |
| New Sessions/Second (TCP) |
640,000 |
| Maximum Firewall Policies |
200,000 |
| IPsec VPN Throughput (512 byte packets) |
45 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
40,000 |
| Client-to-Gateway IPsec VPN Tunnels |
64,000 |
| SSL-VPN Throughput |
9 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum) |
25,000 |
| IPS Throughput (HTTP / Enterprise Mix) |
25 / 18 Gbps |
| SSL Inspection Throughput |
15 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
8,805 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
3.97 Million |
| Application Control Throughput |
36 Gbps |
| NGFW Throughput |
15 Gbps |
| Threat Protection Throughput |
13.5 Gbps |
| CAPWAP Throughput |
15 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 500 |
| Maximum Number of FortiTokens |
20,000 |
| Maximum Number of Registered FortiClients |
20,000 |
| Maximum Number of FortiAPs (Total / Tunnel) |
4,096 / 1,024 |
| Power Consumption (Average / Maximum) |
250 / 278 W |
| Heat Dissipation (Average) |
948.6 BTU/h |
| Operating Temperature |
23–131°F (-5–55°C) |
| Storage Temperature |
-40–158°F (-40–70°C) |
| Humidity |
10–90% non-condensing |
| Certifications |
FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
| NEBS Certified |
– |
